EPEVER 20A Solar Controller MPPT Solar Panel Charge Controller (Certificate)

From Great Range Products
EPEVER 30A Solar Charge Controller MPPT Solar Panel Charge Controller
12 Month Warranty

The Epever Tracer-AN Series 2210 Solar Controller is a smart addition to solar power systems with lead-acid or lithium-ion batteries.

Featuring an adaptive three-stage charging algorithm, the controller can extend the life cycle of batteries.

Designed with advanced MPPT technology, the controller tracks the maximum power point and acquires the maximum solar energy to improve solar efficiency.

Features

*Advanced MPPT technology with 99.5% efficiency
*Ultra-fast tracking speed and guaranteed tracking efficiency
*Conversion efficiency up to 98%
*LCD display
*3-stage charging
*Recognition and tracking of multiple-peaks maximum power point
*Compatible with lead-acid and lithium-ion batteries
*Functions: Charging power, current limitation, battery temperature compensation,
*real-time datatimdata*Multiple load work modes
*Communication port with professional protection chip
*Wireless monitoring via app or PV software
*Full-load operation without drop in capacity
*Extensive electronic protection
*Weight: 0.94kg
*Dimensions: 220mm x 154mm x 52mm
*Voltage: 12V/24V DC
*Rated Charge and Discharged Current: 20A

Specifications
*Rated Charge Power: 260W/12V 520W/24V
*Max. PV Open Power Circuit VolT: 92V (at 25°C environment temp),100V (minimum operating temp)
*Battery Voltage Range: 8 - 32V
*Common negative grounding
*RS485 Interface: 5V DC/100mA
*Enclosure: IP32
*Working Environment Temperature: -25°C - +50°C
*Relative Humidity: ≤ 95%, N.C

1 x MPPT Tracer 2210 Solar Charging Controller
1 x User Manual
